Akira air conditioner error codes + troubleshooting

Akira air conditioners have a good name in the market because of their high-quality products. Their air conditioners have all the top-notch features needed for an extreme level of convenience and comfort for the users. Although the system is of high quality, problems can occur just like in any other electronic product.

To make things easier for you, we have gathered all the common issues along with their causes and solutions. Though most of the issues can be taken down by yourself, contact an HVAC engineer to inspect the problem and resolve it. Doing so will protect the system from major damages and you from injuries.

Akira air conditioner is experiencing inefficient compressing of the compressor

Causes:

1. The electric current or power is about 20% less than the actual value required for the normal operation of the system.
2. The discharge tube on the compressor is overheating.
3. High pressure and low pressure are almost at the same level.

Solutions:

1. Ensure consistency and enough supply of electric current to the system. Inspect wires and power supply and do repairs if needed.
2. Ensure that the temperature of the discharge tube of the compressor is less than 70℃. Give the unit rest and do general cleaning if overheating.
3. Ensure the pressure has a difference and it is not zero or too less.

The compressor of the Akira air conditioner is locked

Causes:

1. Electric current is exceeding the normal range.
2. The compressor is emitting a humming noise.

Solutions:

1. Using a meter, check the current and ensure it is in the normal range such as 198-220V.
2. Reset the breakers and ensure they aren’t OFF.
3. Inspect the compressor and do repairs of faults. Replace the component if it is completely damaged.

The RUN indicator (in the Green color) on the Akira air conditioner is not lighting up

Causes:

1. The remote controller is not working.
2. The power being supplied to the system is less than required or completely cut.
3. The control PCB or display PCB is malfunctioning.

Solutions:

1. Try another remote to verify that the controller is at fault. Replace the remote control batteries if they are dead.
2. If the voltages are less than 198V, contact a technician to inspect the power supply. Repair or replace the power supply as needed.
3. If voltages are cut, check wires to repair any non-insulated or broken wire.
4. Ensure connectors are also in place.
5. If everything is fine, inspect the main and display PCBs and replace either of them if it’s faulty.

The Akira air conditioner indoor fan is not working correctly or has entirely stopped

1. The power has been disconnected between the indoor fan motor terminals.
2. The indoor unit fan motor capacitor is faulty.
3. The control PCB of the indoor unit is malfunctioning.
4. The indoor unit fan motor is broken.

Solutions:

1. Ensure nothing is stuck in fan blades to restrict them from free movement.
2. Check the wiring and connections between indoor unit fan terminals. Repair any broken wire and replace any broken connector.
3. Replace the fan motor capacitor if it’s weak, malfunctioning, or blown.
4. Contact a licensed technician to inspect the fan motor and ensure it works fine. Do repairs or replacements as needed.
5. Replace the control PCB if it is at fault.

The Akira air conditioner outdoor fan is not functioning correctly or has completely stopped

Causes:

1. Voltage has been cut or low between the terminals of the fan motor.
2. Outdoor unit fan blades have obstructions, clogging, or breakages.
3. The capacitor of the outdoor unit is blown.
4. The main PCB is malfunctioning.
5. The fan motor itself is defective.

Solutions:

1. Try the solutions suggested for “The indoor fan is not working correctly or has entirely stopped” or the previous problem with the Akira air conditioner.
2. Replace the fan blades if they are snapped, bent, or broken.

The compressor of the Akira air conditioner is not starting at all

Causes:

1. On the indoor unit of the system, the voltage is cut or low between compressor terminals.
2. The voltage is low or completely cut between the compressor terminals in the outdoor unit of the system.
3. The compressor running capacitor is weak or blown away due to a short circuit.
4. The OLP (Overload Relay) on the compressor has tripped.
5. Compressor winding has a short circuit.
6. The compressor is defective.

Solutions:

1. Check the power supply for both units and repair it if it is supplying voltages less than 198V.
2. Repair any broken or uninsulated wires between the compressor, terminals, power supply, control PCBs, and between the indoor and outdoor units.
3. Replace the running capacitor on the compressor if it is weak or blown away.
4. Check the OLP and put it back in the functioning position. Ensure the circuit is fine and has no issues.
5. Inspect the control PCBs of both units and replace them if they are faulty.
6. Contact a licensed technician to inspect the compressor winding for a short circuit. Repair or rewind the compressor. Replace the component if it’s too damaged.

The refrigeration system of the Akira air conditioner is not functioning properly

Causes:

1. The refrigerant level is low in the system.
2. The system has leaks or clogging.

Solutions:

1. Change the thermostat to different levels and try switching modes.
2. Using a pressure gauge or a meter, check the refrigerant level in the system. Charge refrigerant with the help of an HVAC engineer if needed.
3. Look through the system and call a technician to repair leaks if there are any.
4. Clean the system while removing any obstructions.

The Akrai air conditioner is not providing COOLING or HEAT while the fan of only the indoor unit is operating

Causes:

1. The power is cut off or has some issues.
2. The fan motor of the outdoor unit is faulty.
3. The OLP in either of the units has tripped or blown away.
4. The system has clogging and obstruction.

Solutions:

1. Check the power and ensure a consistent supply of voltages to the system. Repair power supply and wiring if they have issues.
2. Clean the coils, compressor, evaporator, condenser, and all related components to remove any dirt buildup or foreign objects restricting the system from operating in full swing.
3. Reset the OLP and replace it if it is damaged.
4. Replace the control PCB if they are malfunctioning.
5. If the error remains, inspect the compressor for malfunctioning. Repair or replace the components as needed.

The Akrai air conditioner is not providing COOLING or HEAT while the fans of indoor and outdoor units are operating

Causes:

1. The OLP (Overload Motor Protector) is tripping usually because of:
2. Inconsistent voltages
3. Low outdoor unit air passage or circulation
4. Leakages
5. Very high temperature.
6. The running compressor capacitor is at fault.
7. The system compressor is defective.

Solutions:

1. Reset the OLP and restart the air conditioner after an hour or more.
2. Replace the compressor capacitor if it’s defective.
3. If the error remains, try the solutions suggested for “The Akrai air conditioner is not providing COOLING or HEAT while only the fan of the indoor unit is operating” or the previous problem with the Akira air conditioner.

Water is accumulating, leveling up, or overflowing from the Akira air conditioner indoor unit

Causes:

1. The drainage hose is dry or some items are stuck in there.
2. The port of the drainage pan is clogged.

Solutions:

1. Empty the drainage pan and clean the port and hose. Ensure nothing is stuck in there and the passage is fully open.

The Akira air conditioner is not working either with the indoor unit AUX switch or with its remote controller, at all

Causes:

1. The power supply is not functioning well.
2. The secondary voltage of the transformer is wrong (usually when it is approximately at 17 VAC).

Solutions:

1. Contact an authorized HVAC engineer to inspect the power supply. Repair the component if faulty or replace it if it is completely broken.
2. Replace the main PCB if it is malfunctioning or the transformer’s secondary voltage is at 17 VAC.
3. If the error remains, the transformer is at fault and needs complete replacement.

There is insufficient refrigerant in the Akira air conditioner

Causes:

1. The refrigerant level is less than required in the system.
2. The system has leaks or the gas is leaking.

Solutions:

1. Check the refrigerant level and contact an HVAC engineer to charge the refrigerant for your system.
2. Look through the system for leaks. Repair leaks immediately before starting the unit again.

The capillary tube of the Akira air conditioner is clogged

Causes:

1. The capillary tube is clogged due to dirt or particles stuck in there.
2. The strainer has blockages.

Solutions:

1. Seek professional help to clean the capillary tube or strainer for removing the clogging.
2. Correct or replace the capillary tube if it is damaged.

There is a short circuit in the Akira air conditioner indoor unit

Causes:

1. The indoor unit has a short circuit.
2. The circuit or connectors of the indoor unit are blown.

Solutions:

1. Contact a licensed technician or an authorized electrician to inspect the circuits, wiring, and connectors of the indoor unit. Repair any part that has been blown away due to a short circuit.
2. Reset the breakers if they are tripped.
3. Replace the fuse if it is blown.
4. Inspect the main PCB and replace it if it is malfunctioning.

The outdoor uni if the Akira air conditioner has a heat radiation deficiency

Causes:

1. The outdoor unit has a heat radiation deficiency.

Solutions:

1. Check the refrigerant level and ensure it is at the required level. Do a refill if needed.
2. Look through the heat pump and call a technician if there are any leaks.
3. Seek assistance from a professional to troubleshoot the problem and resolve the issue accordingly.

The Akira air conditioner is experiencing an inefficient compressor

Causes:

1. The system has an inefficient compressor.
2. The compressor is defective.

Solutions:

1. Try the exact solutions suggested for “Akira air conditioner is experiencing inefficient compressing of the compressor” or the first problem mentioned in the article.
2. If the error remains, contact an HVAC engineer to inspect the compressor. Do repairs or replacements as needed.
